Features

1. Intelligent Charging System

• Auto Voltage Detection: Auto-sensing 12V/24V system (manual setup available)
• Multi-Battery Support: Optimized charging profiles for Sealed, GEL, Flooded, and Lithium battery types
• 3-Stage PWM Charging: Boost → Float → Equalization (prevents sulfation in lead-acid batteries, excludes GEL/Li)
• Temp Compensation: Auto-adjusts voltage (-3.0mV/°C/2V) for optimal charging (excludes Lithium)

2. Reliable Load Control & Protection

• 5 Operating Modes: Light Control (10-min delay) | Timer Control (1-14h) | Manual | Debug | Always ON
• Comprehensive Protection: Overcharge/discharge, overload, short-circuit, and reverse polarity protection

3. User-Friendly & Durable Design

• Clear LCD Display: Dot-matrix screen with real-time monitoring
• Simple 2-Button Control: Adjust settings easily (memory retains configurations)
• Rugged Build: IP30 enclosure, operates from -13°F to +131°F
